Lenticular Sheet

Lenticular Sheet

General Description

Our lenticular material is a clear, print-grade plastic sheet that has a series of longitudinal lenses extruded into the surface that can produce 3-D, flip, animation, or morph effects. Lenticular printing creates an illusion of depth or motion, making it ideal for marketers, advertisers and printers that want to make an impact with their graphic arts materials.


Properties Test Method Value UOM
Resin n/a 55 Series - APET n/a
Resin n/a 65 Series - PETG n/a
Yield Factor @0.018” polish/polish n/a 55 Series – 1,157 in2/lb n/a
Yield Factor @0.018” polish/polish n/a 65 Series - 1,211 in2/lb
Surfaces n/a Top side – Smooth, Gloss n/a
Surfaces n/a Bottom side – lenticular lens n/a
Sheet Length Range (Lens Direction or LD) n/a Min – 19” (483 mm) LD n/a
Sheet Length Range (Lens Direction or LD) n/a Max – 100” (2,540 mm) LD n/a
Sheet Width Range n/a Min – 19” (483 mm) LD n/a
Sheet Width Range n/a Max – 47” (1,194 mm) LD n/a
Surface Tension n/a Natural ST= 42 dyne n/a
Sheet Length Tolerance n/a -0, +0.0625” (1/16”, 1.6 mm) n/a
Sheet Width Tolerance n/a -0, +0.0625” (1/16”, 1.6 mm) n/a
Spartech Lenticular Sheet

Product Information

Item Description
Product Line Spartech
Item Code Lenticular Sheet
Material Description Lenticular Sheet
Product Description 3D and Motion Effect Imaging


Polymer Tag Polymer Name
PE Polyethylene
PET Polyethylene Terephthalate

Related Documents

Title Open
TDS—Lenticular sheet Open
