General Description
This clear, print-grade plastic sheet has a series of longitudinal lenses extruded into the surface that can produce a 3D, flip, animation, or morph effects. Lenticular printing creates an illusion of depth or motion, making it ideal for marketers, advertisers and printers that want to make a unique impact with their graphic arts materials.
Technical
| Properties |
Test Method |
Value |
UOM |
|---|
| Resin |
n/a |
55 Series - APET |
n/a |
| Resin |
n/a |
65 Series - PETG |
n/a |
| Yield Factor @0.018” polish/polish |
n/a |
55 Series – 1,157 in2/lb |
n/a |
| Yield Factor @0.018” polish/polish |
n/a |
65 Series - 1,211 in2/lb |
n/a |
| Surfaces |
n/a |
Top side – Smooth, Gloss |
n/a |
| Surfaces |
n/a |
Bottom side – lenticular lens |
n/a |
| Sheet Length Range (Lens Direction or LD) |
n/a |
Min – 19” (483 mm) LD |
n/a |
| Sheet Length Range (Lens Direction or LD) |
n/a |
Max – 100” (2,540 mm) LD |
n/a |
| Sheet Width Range |
n/a |
Min – 19” (483 mm) LD |
n/a |
| Sheet Width Range |
n/a |
Max – 47” (1,194 mm) LD |
n/a |
| Surface Tension |
n/a |
Natural ST= 42 dyne |
n/a |
| Sheet Length Tolerance |
n/a |
-0, +0.0625” (1/16”, 1.6 mm) |
n/a |
| Sheet Width Tolerance |
n/a |
-0, +0.0625” (1/16”, 1.6 mm) |
n/a |
