Royalite® R552

Royalite® R552

General Description

Royalite R552 is UL 94V-0 and UL94 5VA, flame retardant extruded sheet product manufactured from recycled PVC/Acrylic resin. The excellent balance of physical and mechanical properties, combined with its flame rating, make R552 an excellent, cost effective choice for a wide variety of applications in the electronics, equipment, and materials handling industries.

Technical

Properties Test Method Value UOM
Specific Gravity (color dependent) ASTM D-792 1.35 n/a
Tensile Strength ASTM D-638 5,500 psi
Flexural Strength ASTM D-790 9,000 psi
Flexural Modulus ASTM D-790 300,000 psi
Izod Impact (Notched) 72°F ASTM D-256 7.5 ft-lbs/in
Rockwell Hardness (R Scale) ASTM D-785 96 n/a
Heat Deflection Temperature @264 psi, Annealed ASTM D-648 150 °F
Motor Vehicle Safety Standard FMVSS 302 Passes n/a
Flammability UL 94 V-0 Listed @ 0.030" n/a
Flammability UL 94-5VA Listed @ 0.090" n/a
Flammability - FAA - Vertical Burn - 60 second FAR 25.853a (i) Passes n/a

Performance

Properties Test Method Value UOM
Chemical Resistancen/an/a
Flexural Modulus (stiffness)n/aVery Highn/a
Formabilityn/aGoodn/a
Gloss After Formingn/an/a
Hardnessn/aVery Highn/a
Heat Deflection Temperaturen/aAveragen/a
Impact Strengthn/aVery Highn/a
Low Temperature Impact Strengthn/aAveragen/a
Tensile Strengthn/aVery Highn/a
UV Resistancen/aGoodn/a
Spartech Royalite® R552

Product Information

Item Description
Product Line Royalite®
Item Code Royalite® R552
Material Description PVC/Acrylic 100% Recylcled
Product Description Fire-rated PVC/Acrylic rigid sheet, 100% recycled content
Characteristics
  • High flexural modulus
  • High impact strength
  • Recyclable
  • Can be designed up to 100% recycled content
  • Available in standard and custom colors, thicknesses and sizes
  • Listed: UL 94 V-0 @ 0.030"
  • Listed: UL 94 5VA @ 0.090"
BenefitsOur sheet solutions protect medical and electronic components as well as the environment. At Spartech, we designed our Royalite® R552 and R559 flame and smoke-rated sheets to protect the most sensitive technology components. We also repurpose trim material during manufacturing to save energy and minimize waste to help protect the environment.
ApplicationsMedical and electronic components and enclosures

Polymers

Polymer Tag Polymer Name
RPVC Rigid Polyvinyl Chloride
Alloy Thermoplastic Alloy

Related Documents

Title Open
Royalite® R552 and R559 Flame and smoke-rated sustainable sheet solutions Open
Royalite® Product Line Bulletin Open
TDS—Royalite® R552 Open
AIS—Royalite® R552 Open
Royalite® RoyalAero™ Brochure Open

*All values based on 0.125" unless otherwise stated

Customers are responsible for determining whether products and information are appropriate for their use, including the evaluation of all applicable laws. Spartech LLC assumes no liability for the accuracy or completeness of information contained herein, and such information is subject to change without notice. All products supplied are subject to the standard terms and conditions of sale of Spartech LLC. NO WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, IS MADE BY THIS TECHNICAL DATA SHEET. ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY EXCLUDED.
