Royalite® R503

Royalite® R503

General Description

Royalite® R503 is a flexible, low gloss, fire-rated, recyclable proprietary thermoplastic sheet specifically formulated to meet the requirements of the FAR 25.853(a) flammability* test. Royalite® R503 combines extremely high impact strength with moderate stiffness with excellent formability in deep draws.


Properties Test Method Value UOM
Specific Gravity (color dependent) ASTM D-792 0.93 n/a
Hardness (Shore A) ASTM D-2240 93 n/a
Tensile Strength ASTM D-412 1065 psi
Tensile Elongation @ Break ASTM D-412 12.25 n/a
Flexural Modulus ASTM D-790 1,700 psi
Izod Impact (Unnotched-Machine Direction) 72°F ASTM D-256 No Break n/a
Instrumented Impact - Total Energy at 72°F ASTM D-3763 18 ft lbs
Instrumented Impact - Total Energy at -30°C ASTM D-3763 20 ft lbs
Heat Deflection Temperature @66 psi ASTM D-648 104 °F
Taber Abrasion ASTM D-1044 No Wear Through n/a
Tear Strength - Die C ASTM D-624 98.5 psi
Gardner Gloss ASTM D-523 < 5.0 Gloss Units-60°
Flammability - Vertical Burn - 12 second FAR 25.853a (ii) Passes at 0.120” n/a
Spartech Royalite® R503

Product Information

Item Description
Product Line Royalite®
Item Code Royalite® R503
Material Description Royalite® R503
Product Description Fire-rated TPR flexible sheet
CharacteristicsPasses: FAR 25.853 (a)(ii) @ 0.120"


Polymer Tag Polymer Name
TPR Thermoplastic Rubber

Related Documents

Title Open
Royalite® Product Line Bulletin Open
AIS—Royalite® R503 Open
Royalite® RoyalAero™ Brochure Open

*All values based on 0.125" unless otherwise stated
