Royalite® R105

Royalite® R105

General Description

Royalite® R105 is a soft, vinyl foam laminated FR PVC/Acrylic sheet. Royalite® R105 is designed for aircraft cabin, cockpit, and seat components. The sheet has excellent physical characteristics such as impact strength and ductility. Royalite® R105 passes FAR 25.853 (a)(i) @ 0.125" and FAR 25.853 (a)(ii) @ 0.125".

Technical

Properties Test Method Value UOM
Specific Gravity (color dependent) ASTM D-792 1.04 n/a
Tensile Strength ASTM D-638 4,000 psi
Flexural Modulus ASTM D-790 77,100 psi
Heat Deflection Temperature @264 psi ASTM D-648 69 °C
Hardness - Shore D ASTM D-2240 73 n/a
Izod Impact (Notched) 72°F ASTM D-256 12.2 ft-lb/inch
Flammability - FAA - Vertical Burn - 60 sec FAR 25.853a (i) Passes n/a
Flammability - Vertical Burn - 12 second FAR 25.853a (ii) Passes n/a
Spartech Royalite® R105

Product Information

Item Description
Product Line Royalite®
Item Code Royalite® R105
Material Description Royalite® R105
Product Description PVC/Acrylic

Polymers

Polymer Tag Polymer Name
RPVC Rigid Polyvinyl Chloride
Alloy Thermoplastic Alloy

Related Documents

Title Open
TDS-Royalite® R105 Open
Royalite® RoyalAero™ Brochure Open

Customers are responsible for determining whether products and information are appropriate for their use, including the evaluation of all applicable laws. Spartech LLC assumes no liability for the accuracy or completeness of information contained herein, and such information is subject to change without notice. All products supplied are subject to the standard terms and conditions of sale of Spartech LLC. NO WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, IS MADE BY THIS TECHNICAL DATA SHEET. ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY EXCLUDED.
