Royalite® R49/52
Royalite® R49/52
General Description
Class 1/A rated sheet for building and construction applications, Royalite® R49/52 is an excellent material for wall coverings, ceiling tiles and a myriad of other architectural application where stringent building codes are required for pharmaceutical, food, and electronic cleanrooms. R49/52 is available in many colors in thicknesses from .020” - .250” and is UL listed. R49/52 has good formability and is easy to work with when additional fabrication is needed.
Technical
| Properties | Test Method | Value | UOM |
|---|---|---|---|
| Specific Gravity (color dependent) | ASTM D-792 | 1.35 | n/a |
| Izod Impact (Notched) 72°F | ASTM D-256 | 15 | ft-lbs/in |
| Tensile Strength | ASTM D-638 | 5,800 | psi |
| Flexural Strength | ASTM D-790 | 9,500 | psi |
| Flexural Modulus | ASTM D-790 | 320,000 | psi |
| Rockwell Hardness (R Scale) | ASTM D-785 | 95 | n/a |
| Heat Deflection Temperature @264 psi, Annealed | ASTM D-648 | 150 | °F |
| Flammability - Steiner Tunnel (1) | ASTM E-84 | Passes | n/a |
Performance
| Properties | Test Method | Value | UOM |
|---|---|---|---|
| Chemical Resistance | n/a | n/a | |
| Flexural Modulus (stiffness) | n/a | Very High | n/a |
| Formability | n/a | Good | n/a |
| Gloss After Forming | n/a | n/a | |
| Hardness | n/a | Very High | n/a |
| Heat Deflection Temperature | n/a | Average | n/a |
| Impact Strength | n/a | Very High | n/a |
| Low Temperature Impact Strength | n/a | Average | n/a |
| Tensile Strength | n/a | Very High | n/a |
| UV Resistance | n/a | Good | n/a |
Product Information
| Item | Description |
|---|---|
| Product Line | Royalite® |
| Item Code | Royalite® R49/52 |
| Material Description | PVC/Acrylic |
| Product Description | Fire-rated PVC/Acrylic rigid sheet |
| Characteristics |
|
| Benefits | Class-A: ASTM E-84 @ 0.080", bonded to cement board |
| Applications |
|
Polymers
| Polymer Tag | Polymer Name |
|---|---|
| RPVC | Rigid Polyvinyl Chloride |
| Alloy | Thermoplastic Alloy |
Related Documents
| Title | Open |
|---|---|
| Royalite® Product Line Fire-rated and other specialty sheet solutions | Open |
| TDS—Royalite® R49 52 | Open |
| AIS—Royalite® R52 W R49 | Open |
*All values based on 0.125" unless otherwise stated
(1) 0.080” and bonded
